2.4m Heavy-Duty Perforated Cable Tray DXF | CNC Sheet Metal Fabrication Files | PDF & STL Download

Organize and protect electrical cables with this Heavy-Duty Perforated Cable Tray, professionally designed for strength, efficient cable management, and easy installation. With a maximum standard length of 2400 mm (2.4 m), this tray is ideal for commercial, industrial, and residential electrical installations.

The ventilated perforation pattern promotes excellent airflow, helping to reduce heat buildup around power and data cables while minimizing overall tray weight. Designed with rolled safety edges for increased rigidity and safe handling, this cable tray is optimized for CNC fabrication and sheet metal bending.

Whether you’re manufacturing cable trays for electrical contractors or fabricating custom cable management systems, these production-ready files will save valuable design time.

What’s Included

Your instant digital download includes:

• ✅ DXF File (CNC Laser, Plasma & Punch Ready)
• ✅ PDF Fabrication Drawing
• ✅ STL 3D Model

All files are professionally prepared and ready for fabrication.

Product Features

• Maximum tray length of 2400 mm (2.4 m)
• Strong U-channel profile with reinforced rolled edges
• Ventilated perforations for improved cable cooling
• Lightweight yet durable construction
• Optimized for sheet metal fabrication
• Easy to scale and customize
• Production-ready fabrication drawings
• Suitable for indoor and outdoor installations (material dependent)

Recommended Materials

This cable tray can be manufactured from:

• Mild Steel (MS)
• Pre-Galvanized Steel (GI)
• Hot-Dip Galvanized Steel
• Stainless Steel (SS304 / SS316)
• Aluminum

Recommended Material Thickness

Depending on the load requirements:

• 1.0 mm – Light-duty installations
• 1.2 mm – General-purpose applications
• 1.5 mm – Medium-duty installations
• 2.0 mm – Heavy-duty applications
• 2.5–3.0 mm – Industrial and high-load environments

Applications

Ideal for:

• Commercial buildings
• Industrial factories
• Data centers
• Hospitals
• Warehouses
• Shopping malls
• Manufacturing plants
• Office buildings
• Solar installations
• Cable routing in workshops and production facilities

Customization Available

The design can be modified to suit your project requirements, including:

• Tray width
• Sidewall height
• Material thickness
• Perforation pattern
• Mounting hole positions
• Slot dimensions
• Tray length
• Reinforcement features
• Connector and splice plate compatibility

Machine Compatibility

Compatible with:

• CNC Fiber Laser Cutters
• Plasma Cutting Machines
• CNC Turret Punch Presses
• Waterjet Cutting Machines
• Press Brakes
• Sheet Metal Folding Machines

Benefits

• Professional fabrication drawings included
• Reduces engineering and drafting time
• Clean, production-ready cutting profiles
• Easy to modify for custom projects
• Improves cable organization and ventilation
• Designed for efficient manufacturing
• Suitable for both small workshops and large-scale production

Important Notice

This product is a digital download only. No physical cable tray will be shipped. The download includes fabrication files for manufacturing and can be customized to meet your specific project requirements.
